GC77
Sliding SystemGC77 system presents solution for casement windows and doors allows installation and thermal insulation from the outside and includes three different levels of thermal insulation in order to meet buildings’ energy performance requirements.The system is available in a variety of shapes to match architectural requirements offering all types of both inward and outward opening casement windows.Different inner and outer colors are possible.
| Descriptions | Value | |
|---|---|---|
| Frame Depth: | 77 mm. | |
| VentDepth: | 87 mm. | |
| GlassThickness: | Up to 60 mm. | |
| RebateHeight: | 22 mm | |
| GlazingType: | Dry Galazing with EPDM | |
Technical performance:
GC77 system presents solution for casement windows and doors allows installation and thermal insulation from the outside and includes three different levels of thermal insulation in order to meet buildings’ energy performance requirements.The system is available in a variety of shapes to match architectural requirements offering all types of both inward and outward opening casement windows.Different inner and outer colors are possible.
